As technology advances, so do connection standards. USB 5 promises faster speeds, improved power delivery, and wide compatibility. This article explores its specs, bandwidth, and impact on your devices.
USB 5 is the unofficial name for the next-generation USB specification developed by the USB Promoter Group. While an official name may eventually be USB4 Version 2.0 or another designation, many in the tech community are referring to it as USB 5 due to its progression beyond USB4.
The goal of USB 5 is to improve data transfer speeds, power efficiency, and protocol versatility, particularly in high-performance computing environments. It is designed to cater to demanding use cases like 8K video streaming, ultra-fast SSD storage, and power-hungry peripherals.
The USB Promoter Group—which includes Intel, Microsoft, Apple, HP, and others—has indicated that USB 5 will continue the legacy of the USB Type-C connector, focusing on bandwidth doubling and enhanced functionality over existing USB4 infrastructure.
The USB 5 specification builds upon USB4 and Thunderbolt 4 foundations. Here are the key technical upgrades and features:
One of the most anticipated improvements is the doubling of maximum bandwidth from 40 Gbps (USB4) to 80 Gbps. This is achieved using a new PAM3 (Pulse Amplitude Modulation) signaling method over existing USB Type-C cables, offering high-speed data transmission with minimal signal degradation.
USB 5 is designed to allow asymmetric data rates, meaning it can support 120 Gbps in one direction and 40 Gbps in the other, ideal for high-performance displays or data transfer needs where output is prioritized.
USB 5 expands support for external displays by improving DisplayPort tunneling performance and PCI Express (PCIe) protocols. This will help power next-gen external GPUs, VR headsets, and 8K monitors with greater efficiency and less latency.
As with USB4, USB 5 is expected to retain Thunderbolt 3 and Thunderbolt 4 compatibility, ensuring interoperability with a wide range of existing high-speed peripherals.
There’s no need to worry about new cables or plugs. USB 5 will continue to use the USB Type-C connector, which has become the industry standard for modern laptops, tablets, smartphones, and accessories.
This decision not only preserves consumer investment in cables and ports but also simplifies device manufacturing, as one port can handle power, video, and data transfer with a single, reversible connector.
USB 5’s 80 Gbps bandwidth is twice the speed of USB4 and eight times faster than USB 3.2 Gen 2x2 (10 Gbps). This advancement supports high-resolution video output, ultra-fast NVMe SSDs, and faster backups.
Transfer a 100GB file in just 10–12 seconds, depending on storage performance.
Stream 8K video at 60Hz without compression, ideal for professional video editors and streamers.
Run external GPUs or AI accelerators at nearly native performance using PCIe tunneling.
These bandwidth gains mean smoother multitasking, faster project completion, and more responsive computing across professional and personal setups.
Although USB 5 does not introduce a new power delivery standard on its own, it will be compatible with USB Power Delivery (USB PD) 3.1, which supports up to 240W of power transfer.
Faster charging for high-performance laptops and gaming devices.
Single-cable solutions for docking stations and external monitors with power, data, and video.
Improved thermal and power efficiency in smaller devices that demand higher wattage.
This ensures USB 5 remains future-proof not just in speed but also in power handling capabilities.
Backward compatibility remains a critical feature for USB, and USB 5 does not disappoint.
USB4
USB 3.2
USB 2.0
Thunderbolt 3 & 4
Older devices will still work when connected via USB 5 ports, although they will operate at their native speeds. For example, plugging a USB 2.0 flash drive into a USB 5 port will still work—it just won’t enjoy any speed improvements.
This means users won’t need to replace all their peripherals immediately and can enjoy a seamless transition into next-gen computing.
Feature | USB4 | USB 5 |
Max Bandwidth | 40 Gbps | 80 Gbps |
Connector Type | USB-C | USB-C |
Power Delivery | Up to 240W (with USB PD 3.1) | Same |
Thunderbolt Support | Yes (optional) | Yes (likely standard) |
DisplayPort Tunneling | Yes | Enhanced |
PCIe Tunneling | Yes | Improved |
Backward Compatibility | Yes | Yes (same range) |
While USB4 was a substantial leap over USB 3.2, USB 5 doubles down on speed and better supports next-generation applications like 8K video, AI peripherals, and external GPUs.
For video editors, photographers, and animators dealing with massive file sizes, USB 5 drastically cuts transfer times and allows real-time preview on ultra-HD monitors.
External GPUs, high-speed SSDs, and low-latency accessories benefit from USB 5’s bandwidth and responsiveness, especially in competitive settings or VR.
Data scientists, CAD engineers, and software developers using high-bandwidth peripherals, AI chips, or large databases will appreciate the time-saving advantages.
Even casual users will enjoy faster charging, quicker backups, smoother 4K+ video streaming, and better peripheral performance—without needing to upgrade everything at once.
This depends on the device and manufacturer. USB 5 will support existing USB-C cables, but to unlock the full 80 Gbps, a certified USB 5 cable with PAM3 signaling may be required.
Cables used for USB4 at 40 Gbps will still work but may limit you to previous-gen performance.
To make use of asymmetric 120 Gbps/40 Gbps modes (e.g., high-res displays), certified cables will be necessary.
As of 2025, USB 5 is still in the development or rollout phase. Some manufacturers are already testing early hardware, and commercial availability is expected in late 2025 or early 2026, depending on certification and ecosystem readiness.
The USB Implementers Forum (USB-IF) is responsible for branding, certification, and compliance testing, ensuring that only reliable and standardized products make it to market.
With so many versions—USB 3.2 Gen 1, Gen 2x2, USB4, and now USB 5—consumers may find it hard to differentiate between cable types and speeds. Clear labeling and education will be critical.
Initially, USB 5-enabled devices and certified cables will be more expensive than their predecessors. Early adopters should factor in costs for optimal cables and compatible hardware.
While backward compatibility is a strength, not all devices will benefit equally from USB 5. You’ll need both host and peripheral devices that support USB 5 to realize its full performance.
USB 5 is a major step, but it won’t be the end. As computing demands increase—driven by AI, VR, 8K+ media, and edge computing—USB specifications will continue evolving. Future USB iterations may explore:
160 Gbps+ speeds
Lower latency for real-time applications
Tighter integration with AI hardware
Expect the USB Promoter Group to continue pushing boundaries while maintaining the USB core principle: a universal, easy-to-use, backward-compatible standard.
USB 5 brings 80 Gbps speeds, better signal processing, and broad compatibility—meeting the needs of modern users. Built on USB-C with backward support, it promises faster, smarter connectivity. Though adoption may take time, its long-term impact will be substantial.
